T16 2.25" Compact-Optimized Single-Chamber Brake Actuator

Featuring a compact structural design, the T16 serves as an ideal solution for vehicle models with limited installation space. This model features a stroke specification of 2.25 inches (57 mm), and its air inlet is equipped with M16 air port threads, ensuring seamless compatibility with corresponding pneumatic line systems. In terms of manufacturing, the product utilizes a high-strength iron housing with welds that are finished to a smooth, seamless standard, thereby guaranteeing the structural integrity of the unit. Its standard operating air pressure is set at 10 Bar, and it is capable of functioning within a temperature range of -40°C to +80°C, allowing it to withstand extreme low-temperature environments down to minus forty degrees.
To ensure the product's durability across various operating conditions, the housing has successfully passed a 72-hour salt spray test, demonstrating a robust level of corrosion resistance. Throughout the production process, the manufacturer employs high/low-temperature test benches, endurance testers, thickness gauges, and surface roughness testers to rigorously monitor component quality and maintain product consistency. Furthermore, upon request, the manufacturer can provide detailed high/low-temperature and endurance test reports specific to the ordered batch. This product also supports extensive customization services; users can tailor the pushrod length, surface treatment processes, and yoke styles to meet their specific requirements, while also selecting from a diverse range of packaging options—including laser marking services, custom labeling, inner bags, and full-color retail boxes.

PREV：T20 2.25" Universal Standard Brake Chamber NEXT：No next product

Description
Contact Us

Operating temperature range: -40°C to +80°C
Supplied in the parking brake position
Available colours: yellow/black/red
Once the product has passed testing, the air inlet is fitted with a matching threaded protective plug
The push rod is fitted with a matching coloured threaded protective sleeve
The product is placed in a protective bag when packed

E: Stus Spacing 120.7mm J: Pushrod thread K: Distance from top cover to center of Clevis Pin(mm) Stroke: 2.25inch=57mm 2.5inch=63.5 3inch=76mm
TYPE	Stroke(inch)	E	J	K	Hole
T16	2.25
	2.5	120.7with 5/8-11UNC	5/8-18UNF	90	M16*1.5
	2.5	120.7with 5/8-11UNC	/	57		SC16LCW
	3	120.7with M16*1.5	M16*1.5	186	M16*1.5	0834481
